GXSC GX85RS128 enables efficient, low-power solutions for surveillance systems, comparable to MB85RS128/FM25V01

Surveillance systems have become an essential tool for ensuring public safety and maintaining social order. As surveillance systems continue to evolve, the demands on data storage have grown increasingly stringent, requiring not only high-capacity, high-speed storage devices but also features such as high reliability and low power consumption. The GXSC GX85RS128, as a new type of non-volatile memory, offers a high-performance solution that provides an efficient, reliable, and low-power storage solution for surveillance systems.

The storage cells of the FRAM GX85RS128 can withstand 1 billion read/write operations, making it highly suitable for frequent data write operations in surveillance systems, such as real-time recording of surveillance videos and alarm information, without concerns about storage damage or data loss due to limited erase/write cycles. It operates at a frequency of up to 25MHz and supports 40MHz high-speed read commands, enabling rapid storage of data into the memory.

One of the core tasks of a surveillance system is to record video footage in real-time from the monitored area. In traditional surveillance systems, DVRs or NVRs are typically used in conjunction with hard drives for video storage. However, hard drives are prone to failure under frequent read/write operations and have relatively slow read/write speeds, making it difficult to meet the real-time storage requirements for high-definition and ultra-high-definition video. The GX85RS128‘s fast read/write speeds and unlimited erase cycles make it an ideal choice for video data storage, not only improving storage efficiency but also effectively preventing video data loss caused by network latency or backend storage device failures.

Key specifications of the GX85RS128:

• Capacity: 128Kb

• Interface type: SPI interface (Mode 0 and Mode 3)

• Operating voltage: 2.7V to 3.6V

• Operating frequency: 25MHz

• Power consumption: 4.2mA, 9uA (standby)

• Data retention: 10 years at 85°C (200 years at 25°C)

• High-speed read capability: Supports 40MHz high-speed read commands

• Operating temperature range: -40°C to 85°C

• Package type: 8-pin SOP package, RoHS compliant

• Replaces Fujitsu MB85RS128 and Cypress FM25V01
