GX85RS2MC in Enterprise SSD Compatible with FM25V20A

The two key components of an SSD are the flash processor and the non-volatile memory used to store the data. For enterprise SSDs, in typical data center scenarios involving the processing of millions of bytes of random corporate data, including collaboration on CAD technical drawings, seismic data for analytics, or access to global customer data for banking transactions, it is imperative that the storage device be accessed with the least amount of latency and that it can involve clients that need to access the same data concurrently without impacting response times.

FRAM GX85RS2MC core technology is a ferroelectric process and silicon gate CMOS process technology to form a non-volatile memory cell, GX85RS2MC has the advantages of fast read/write speed (1,000,000 times), long write life, and low write energy consumption. In case of abnormal power loss, the GX85RS2MC utilizes the high-speed write characteristics to instantly save FTL Changes and Write Buffer into the GX85RS2MC, which completely solves the problem of data loss caused by abnormal power loss of enterprise-class SSDs. Please feel free to contact us at service_jesseli@gxschip.com.

GX85RS2MC application introduction:

- Interface type: SPI interface;

- Operating frequency: 25 MHz;

- Data retention: 10 years @ 85℃ (200 years @ 25℃);

- High-speed read characteristics: support 40MHz high-speed read command;

- Operating ambient temperature range: -40°C to 85°C;

- Package: 8-pin SOP package, RoHS compliant;

- Performance compatible with MB85RS2MT (Fujitsu) and FM25V20A (Cypress).
