GXSC GX24C512 for Low Power Digital Pressure Calibration Gauge, Replacement for MB85RS512

A powerful portable professional intelligent digital pressure calibration meter, it can measure pressure, current, voltage, temperature, switching, time and other items, and its small size, easy to operate, easy to use for on-site calibration of the instrument as well as precision pressure measurement. In order to ensure the safety and integrity of the data, it is necessary to record and save the pressure calibration data for a long period of time. The non-volatile memory has higher durability and reliability, which can satisfy the frequent data storage and updating needs of the digital pressure calibration meter in the process of long-term use.

The GXSC FRAM GX24C512 is formed by ferroelectric process and silicon gate CMOS process technology to form a non-volatile memory cell, which can support 1 million read/write operations, and has higher durability and reliability compared with flash memory and E²PROM memory, and ensures that the stored pressure calibration data will not be lost even in the event of an unexpected power failure.

FRAM GX24C512 Main Parameters:

- Capacity: 512Kb

- Interface type: IIC interface

- Operating voltage: 1.7V to 5.5V

- Operating frequency: 1MHz

- Power consumption: 4.2 mA, 9uA (standby)

- Data retention: 10 years @ 85°C (200 years @ 25°C)

- Operating ambient temperature range: -40°C to 85°C

- Package: 8-pin SOP package, RoHS compliant

- Replaces Fujitsu MB85RS512 and Cypress FM25V05

With 0.5mA (typical @ 1MHz) and a standby current of only 1µA (typical conditions) when the digital pressure calibration gauge is in standby or sleep, this GX24C512 chip ensures that devices that need to be in standby for long periods of time, but need to be quickly activated at any time to perform a pressure calibration, will maintain sufficient power for accurate measurements after a long period of time in standby.
